New Technical Details of the Next Generation Acura NSX Revealed at SAE 2015 World Congress and Exhibition

New information disclosed on innovative powertrain, body and manufacturing technologies further solidifies the NSX's position as a world-class supercar

- NSX legacy of innovative, lightweight body design for high performance is advanced with world's first automotive application of ablation casting

- Total airflow management design strategy employed to achieve world-class supercar performance

DETROIT -- April 23, 2015: In advance of the market launch of the highly anticipated next generation Acura NSX, the engineers leading the supercar's development shared new technical details and design strategies with the automotive engineering community at the April 22nd SAE Detroit Section dinner, held in conjunction with the SAE 2015 World Congress and Exhibition. Additional information about the team's efforts to achieve a true "New Sports Experience" included details of the NSX's world's first body construction process that helped create a multi-material space frame resulting in class-leading body rigidity, the advanced total airflow management system and an update on NSX's power unit specifications.

Ted Klaus, chief engineer and global development leader of the new NSX, introduced key powertrain, body and dynamic performance engineers who shared new product and technical details in their related areas of the development. The unprecedented sharing of technical details prior to the car's market introduction reflects the desire of the NSX development team and the company to inspire the imagination of automotive and technology enthusiasts along with the next generation of engineers.

"Our goal is to create something altogether new and exciting, something that advances the concept of a next generation supercar in the spirit of the original NSX," said Klaus. "In order to provide NSX-level value, we needed to push ourselves to experiment with, refine and then realize many new technologies."

Significant technical revelations concerning the NSX included:

• The NSX includes Acura's first use of a revolutionary multi-material space frame design that delivers class-leading body rigidity while remaining lightweight.
• World's first automotive application of new ablation casting¹ technology resulting in world-class body rigidity for ultimate handling and control.
• World's first use of a three-dimensionally formed, ultra-high-strength steel A-pillar, supporting class-leading rigidity and crash performance while providing outstanding outward visibility.
• The NSX achieves top-in-class aerodynamics targets without the use of active aerodynamic elements, while its three-motor Sport Hybrid power unit is cooled through 10 heat exchangers all thanks to a total airflow management strategy that maximizes the flow of air around and through NSX.
• Displacement of the NSX's all-new twin turbo V-6 engine was confirmed to be 3.5-liters.
• The NSX will mark the introduction of the most capable and highest torque capacity Super Handling All-Wheel Drive system in Acura history.
• The latest proprietary logic advances Acura's two decades-long pursuit of Super Handling that proactively responds to driver inputs, allowing the NSX to achieve a new level of line trace while at the same time intelligently supporting the driver in changing environments.

"For this new NSX development, anything and everything that could offer incredible base rigidity and lightweight design was on the table," said Shawn Tarr, principal engineer and Acura NSX body development leader. "We considered all-aluminum unibody, carbon fiber monocoque and space frame designs and ultimately engineered a multi-material space frame because it offers the lowest weight and best rigidity, precision and hybrid powertrain packaging capability of any design."

A key advancement in casting technology allowed the NSX development team to realize a quantum leap in body design, for the first time being able to engineer a vehicle with castings in key locations for rigidity, that also support the ductility necessary for placement within crush zones.

World's First Application of Ablation Casting The Acura NSX heralds the world's first application of ablation casting technology in the automotive industry. Ablation casting combines traditional casting methods with rapid cooling techniques to offer the design flexibility and rigidity of casting with the ductility and energy absorption characteristics of extruded material.

• Super Handling is brought to its pinnacle form in NSX where the strengths of electric motors –delivering zero delay acceleration – allows the NSX to offer dynamic torque vectoring even at low vehicle and engine speeds.
• Super Handling logic has progressed along a parallel path with hardware. While many advanced automotive technologies are focused on feedback, measurements of how the vehicle is reacting, NSX uniquely applies additional technology to focus on accurately responding to driver input through immediate, precise application of torque at each wheel at any moment.
• Using cutting edge computer-aided engineering (CAE) optimization software, engineers created a double-wishbone, double lower control arm front suspension that decouples the twin-motor unit (TMU) torque from the driver's experience at the steering wheel, providing timeless sports car steering communication to the driver with a new experience of on rails handling provided by the precise torque vectoring of the TMU.
• Variable gear ratio steering is applied to further enhance the confident, race-ready driving dynamics of the all-new NSX.

Powertrain
Sport-Hybrid SH-AWD Power Unit
Powering the Sport Hybrid Power Unit with Racing Technologies

As announced at the 2015 North American International Auto Show, the new NSX will utilize an all-new power unit from a clean sheet design. At its heart is an all-new longitudinally mounted twin-turbo V6 engine that is mated to an all-new, Acura-developed 9-speed DCT with an electric motor that applies its torque directly to the crankshaft for higher output with immediate power delivery to the rear wheels.

• The new engine has a displacement of 3.5-liters and utilizes pinnacle racing technology, applying both direct and port injection to its design.
• The 75-degree V-angle and dry sump design optimizes engine rigidity and further supports the NSX's Advanced Sports Package by allowing the engine and components to be lowered in the chassis to the maximum extent, resulting in the lowest center of gravity in its class. This also supports the advanced packaging of other engine components.
• The engine's dry sump design also helps maximize vehicle performance in high lateral-G conditions.
• The rear direct-drive electric motor applies its torque directly to the crankshaft.
• The 9-speed DCT's main, counter, secondary and output shaft design maximizes the advanced sports package through a configuration that lowers weight and helps to center the mass nearer the driver.

About NSX
The all-new Acura NSX represents the convergence of timeless sports car values and advanced technology in a pinnacle supercar. Timeless sports car values include classic goals like a rigid and light chassis with the mass placed low and close to the driver. Advanced technologies include those that enhance the driving experience in new ways.

To bring back the legendary NSX the global development team has innovated in the critical, timeless areas of frame and aerodynamics in addition to tirelessly refining its key advanced technology - the state-of-the-art hybrid power unit. The NSX has many innovative components, but the basic recipe is simple: timeless sports car values blended perfectly with advanced technologies that deliver a new sports experience.

About Acura
Acura offers a full line of precision crafted performance-luxury vehicles through a network of approximately 270 U.S. dealers. The Acura lineup features five distinctive models – the RLX luxury flagship sedan, the TLX performance luxury sedan, the ILX sport sedan, the 5-passenger RDX luxury crossover SUV, and the seven-passenger Acura MDX, America's all-time best-selling three-row luxury SUV. The next-generation Acura NSX mid-engine supercar will join the Acura lineup later this year. Acura was recently recognized by Edmunds.com for the third consecutive year as leading all luxury brands in retained value after five years of ownership.

Additional details on each of these engineering achievements follow:

Multi-Material Body
Acura's First Application of a Multi-Material Body with Space Frame Construction
Developing the Most Rigid-in-Class, Multi-Material Body

At the core of the NSX mission to deliver timeless sports car values is an aluminum-intensive, multi-material space frame. This innovative space frame represents a next-generation leap in body design with class-leading technology that is exclusive to Acura within the automotive market. Based on internal data, the all-new Acura NSX multi-material body is by far the most rigid in its competitive set.

While the all-aluminum monocoque body of the original NSX was ahead of its time, current aluminum and ultra-high-strength steel-intensive body architecture has been taken to the limit for supercar design.
