Audi-Backed CO2 Project Gets to the Root of the Problem

MILTON KEYNES, UNITED KINGDOM - January 7, 2010: Vorsprung durch Technik brand plants 36,000 oak trees to create a CO2 “reservoir” as part of a wide-reaching efficiency initiative

Audi has taken a literal approach to nurturing the proverbial ‘green shoots of recovery’ in 2010 by funding the planting of 36,000 oak trees. Forming the basis of the ‘Oak Forest CO2 Reservoir’ project, the budding mighty oaks cover six hectares in Kosching, near the Audi manufacturing facility in Ingolstadt, Germany, and are the first of a planned series of forestation schemes funded by Audi.

Almost completely destroyed in 2007 by bark beetles, drought and severe storms, the Kösching Forest has been replanted with 36,000 young Pedunculate Oaks with funding from Audi in conjunction with the Bavarian State Forestry and the Chair of Forest Yield Science at the Technical University of Munich. The revitalised forest provides a diverse biosphere for a wide variety of animal and plant species, and equally importantly can also store large amounts of carbon. The aim of the project is to identify the relationships between stand density, CO2 sequestration potential and biodiversity.

The Kösching Forest project will spawn several others on sites with different climatic conditions. Another trial site with an area of four hectares at the Audi production site in Györ, Hungary, will be planted with more than 13,000 Pedunculate Oaks. Plans are underway for additional sites at international locations.

The newly sown forest is a particularly ‘visible’ indicator of the Audi commitment to sustainability and environmental protection, but it is just one example of the numerous measures the prestige car manufacturer is systematically implementing to conserve resources in both the cars themselves and in their production.

Efficiency technologies in products
Audi offers 33 models worldwide whose average CO2 value is below 140 grams per km, placing the brand in a leading position among the premium manufacturers. Fleet CO2 emissions will be reduced by an additional 20 per cent by 2012.

Already the ‘cleanest’ in the premium sector with CO2 emissions of just 109 g/km, the A3 1.6 TDI has also just become available in a new version which cracks the 100 g/km mark with CO2 emissions of only 99 g/km, corresponding to fuel consumption of 74.3mpg.

Engines
Audi engineers are working on several subject areas in the engine sector and are the global leaders with the TFSI and TDI engines. In the TDI engines, the common rail systems work at an injection pressure of 2,000 bar, which allows combustion to be managed extremely precisely and efficiently. The Audi valvelift system is used in many petrol engines to optimize gas exchange. In the normally aspirated V6 engines, it varies the stroke of the intake valves; in the turbocharged 2.0 TFSI, it affects the exhaust valves.

Audi also focuses on lower emissions. In the TDI clean diesel, the ultra low emission system drastically reduces nitrogen oxides in the exhaust, making it the world’s cleanest diesel.

Energy management
Energy management is another important efficiency area. The climate control system for the Audi A4, A5, and Q5 model series combines high performance with particularly low energy consumption. Another technology has found its way into series production in a number of models – a recuperation system for the recovery of electrical energy during the braking and coasting phases.

Intelligent thermal management ensures that the engine reaches its operating temperature more quickly. Many Audi models are already equipped with optional daytime running lights comprising high-efficiency LEDs to reduce fuel consumption while simultaneously enhancing safety.

Transmission
The reduction of internal friction is an important topic and Audi has devoted tremendous effort to optimizing the manual transmission. The six-speed tiptronic and stepless multitronic transmissions have also benefited from a number of detailed improvements for increased efficiency, and they are widely spaced to foster a low-rev driving style.

The new seven-speed S tronic shares this same strength. This new dual clutch transmission takes advantage of the strong pulling power of Audi’s engines and a particularly long final gear ratio to lower both engine speed and fuel consumption. A number of models already come equipped with a “start-stop” system that switches off the engine when the car is stationary. Audi will soon launch another efficiency technology – heating the transmission improves efficiency immediately after a cold start.

Driving resistances
The areas of body and tyres harbour significant potential for reducing driving resistances. Tyres with a low rolling resistance play a major role. Sophisticated refinements to the aerodynamics, such as a fully enclosed underbody in the Audi A4, A5, and Q5 model lines, improves the flow of air around the vehicle. Meanwhile the Audi TT, A8, and R8 have a body built largely or entirely of aluminium according to the principles of the Audi Space Frame (ASF). Reduced fuel consumption is a direct consequence of the savings in weight.

Efficient, resource-friendly production
Reducing the energy consumption and thus lowering CO2 emissions even during the assembly of the vehicle plays a central role in the environmental activities of AUDI AG. Climate protection and carbon dioxide emissions have long been among the leading environmental protection topics.

The search for new and improved processes in this area is a constant one, leading to new projects such as increasing the amount of district heat procured or the use of pioneering renewable energies such as photovoltaics.

Taking the planned expansion of capacity into account, AUDI AG has stated the goal of reducing site-specific and company-specific CO2 emissions by 30 percent relative to 1990 by the year 2020. It is therefore very important to continuously improve the energy efficiency of the production facilities.

Overall energy consumption at the Audi Group has held steady for several years now, despite significantly increased vehicle production. An entire package of targeted projects has made this possible. Energy-saving measures are considered during the planning phase for assembly plants and buildings, for infrastructure and for logistics concerns.

Trigeneration (power-heat-cooling) and waste heat utilization
To optimize energy efficiency, Audi operates a power-heat-cooling trigeneration plant in Ingolstadt. The very efficient energy utilization of the natural gas fuel enables the plant to achieve an efficiency of up to 78 per cent. This reduces CO2 emissions by roughly 25 per cent or 17,200 tons versus conventional power generation.

Audi also procures most of the heat it needs from two, predominantly gas-fired heating plants. Ingolstadt’s waste utilization plant began supplying waste heat to the Audi plant at the start of 2004.

In 2008, Audi procured approximately 90,300 MWh of district heat from this source, saving the emission of 17,878 tons of CO2 at the site. An additional increase to 200,000 MWh is planned, which would enable Audi to meet a large portion of its total demand of 410,000 MWh per year with waste heat. This would enable the Audi plant in Ingolstadt to significantly reduce the amount of heat generated in its gas boilers and thus save up to 45,000 tons of CO2 each year.

Photovoltaics
Audi is making nearly 50,000 square meters of roof space at its Ingolstadt and Neckarsulm sites available to a solar energy investor under the proviso that a variety of different, modern and innovative photovoltaic modules are used.

A particular aim is to promote thinfilm technology, whose production is much less energy-intensive than the production of conventional photovoltaic modules with monocrystalline and polycrystalline cells.

Heat recovery
Heat recovery is a central element of the HVAC systems. Several hundred heat recovery systems are in operation in the grounds of the Ingolstadt plant. One particularly effective type of heat recovery system is the thermal wheel. The use of 19 heat recovery systems at the Audi paint shop extracts approximately 35,000 MWh per year, or the annual heating requirement of roughly 3,270 single-family homes. Expressed as CO2 this corresponds to an annual emissions savings of around 7,000 tons.

Efficient joining processes
Audi uses innovative and efficient joining processes to assemble bodies, including spot welding, laser welding and adhesive bonding. The respective welding technology is matched to the individual joining process so that the most efficient solution for the respective process can be selected.

Electric motor-driven welding tongs have gradually replaced the pneumatic welding tongs in recent years. Energy consumption and thus CO2 emissions are reduced by roughly 50 percent compared to pneumatic welding tongs used the exact same way. Based on the positive experience gleaned with the advanced technology, it will now be considered for all new projects at the Audi Group.
